1200bph 5 Gallon Mineral Water Bottling Machine For Water Production Line

Name: 1200bph 5 Gallon Mineral Water Bottling Machine For Water Production Line
Brand: FILL PACK
Price: 38 USD

Brand Name : FILL PACK

Model Number : QGF-1000

Certification : CE, ISO9001

Place of Origin : ZhangJiaGang JiangSu China

MOQ : 1 set/pcs

Price : USD$38,000.00-USD$43,000.00

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 5 sets/month

Delivery Time : 30-35days

Packaging Details : Wooden case pacakge

bottle size : 3/5 gallon bottle

capacity : 1000BPH

Material : SUS 304

Driven Type : Electric

Core Components : Motor, PLC, Bearing, Engine

Warranty : 1 Year

Function : Bottle Washing Filling Capping

Bottle type : PET Plastic Bottle

Contact Now

1200bph 5 gallon bottles outside brusher machine for water production line

1200bph 5 Gallon Mineral Water Bottling Machine For Water Production Line

1.1, Automatic De-capper

This Gallon bottle outside brusher line is driven by cylinder, controlled by PLC; Automatic working by barrel checking;
De-capping head is composed by claw device and cylinder, de-capping head position can move up and down, claw device can be adjusted slightly to be suitable for different caps.
When the gallon bottle comes into the machine, the de-capping head will go down and claw device will hold tightly barrel cap sides, and then lift the barrel to take off the caps; And when the caps are taken off, the compressor air will blow the caps into cap hopper, then fall outside into client’s own holder;
The claw pressure is adjusted to protect caps;

Parameters
Cap pulling claw	3 pcs
Power	0.2KW
Dimension	12008001950mm
Weight	200kg

1.2, Rotary external washer

General

The Gallon bottle outside brusher line is used for gallon jar outside brush washing; When the jars are sent into the machine by the conveyor, the brushes inside driven by motor will rotate quickly. The main brush shape is made according to jar shape and size which the jar neck and shoulder will be washed completely. Water showing will be done at the same time of brush washing.

Dimension: 1800*1550*1750mm
Weight: 200kg
Power: 3KW

1, Rack: entirely by 75x45 square tube welded stainless steel, high strength, good rigidity, light weight, beautiful appearance, easy to clean and so on. Automatic bottle bodies and chassis welding.
2, Conveyor: driven sprocket, chain, prop bottle rack, solid bottle cups, etc., in which chains, sprockets have been carefully designed to make it more scientific and more perfect.
3, Main driving: frequency control bottle bottle conveyor station every one stays fixed time, chain plate relative to the position of the automatic bottle and the angular position off the bottle also undergo a rigorous calculation to ensure accurate positioning of the entire automatic operation .
4, Adjusting: You can adjust the chain end bearing bolts to ensure that the whole chain of elastic consistency.
The pipes are made of stainless steel washing machine pipe connection, using my company unique rotating spiral nozzle, washing points stronger efforts to good effect, high efficiency no dead ends.
